Floor Cleanouts with Round Extra Heavy Duty Cast Iron Tops

Name: Floor Cleanouts with Round Extra Heavy Duty Cast Iron Tops
Brand: Jay R. Smith Mfg. Co.
SKU: 4220-4234

Model 4220-4234

Floor Cleanouts with Round Extra Heavy Duty Cast Iron Tops

This labor-saving cleanout uses our Twis-to-Floor® adjustment technology to level the top with adjacent surfaces after the floor is poured and floor coverings are installed. Its 7” (180) diam. the cast iron cover is designed for floors where its cast iron appearance is satisfactory. Constructed of Duco-coated cast iron, this cleanout is designed to support heavy load traffic. It is available with 2", 3", 4" and 5" outlets.

Cleanouts are available with No Hub Outlet [Figures 4220S, 4221S, 4223S, 4224S], Inside Caulk Outlet [Figures 4225C, 4226C, 4228C, 4229C] and Speed-Set Outlet [Figures 4231L, 4232L, 4233L, 4234L].

CALIFORNIA WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov - Learn More about this warning

Downloads

Resource Type	Title	Description	File Size
Drawings	4220 Cleanout CAD Drawing	Floor Cleanouts with Round Extra Heavy Duty Cast Iron Tops - No Hub Outlet [Fig. 4220S \| Gasket Seal - ABS Plug]	89 KB
Drawings	4225 Cleanout CAD Drawing	Floor Cleanouts with Round Extra Heavy Duty Cast Iron Tops - Inside Caulk Outlet [Fig. 4225C \| Gasket Seal - ABS Plug]	101 KB
Drawings	4231 Cleanout CAD Drawing	Floor Cleanouts with Round Extra Heavy Duty Cast Iron Tops - Speedi-Set Outlet [Fig. 4231L \| Gasket Seal - ABS Plug]	121 KB
Images	4220 or 4223 Cleanout (hi res jpg)	Floor Cleanouts with Round Extra Heavy Duty Cast Iron Tops - No Hub Outlet [Fig. 4220S \| Gasket Seal - ABS Plug; 4223S - Taper Thread - Bronze Plug]	31 KB
Images	4231 Clean Out (hi res jpg)	Floor Cleanouts with Round Extra Heavy Duty Cast Iron Tops - Speedi-Set Outlet [Fig. 4231L \| Gasket Seal - ABS Plug]	152 KB
Images	4233 Cleanout (hi res jpg)	Floor Cleanouts with Round Extra Heavy Duty Cast Iron Tops - Speedi-Set Outlet [Fig. 4233L \| Taper Thread - Bronze Plug]	24 KB
Submittals	Submittal 4220 Series Cleanout	Floor Cleanouts with Round Extra Heavy Duty Cast Iron Tops - No Hub Outlet [Fig. 4220S \| Gasket Seal - ABS Plug; 4221S \| Gasket Seal - Bronze Plug; 4224S \| Taper Thread - ABS Plug] [Fig 4223S - Taper Thread - Bronze Plug - Exclusive submittal page]	1 MB
Submittals	Submittal 4225 Series Cleanout	Floor Cleanouts with Round Extra Heavy Duty Cast Iron Tops - Inside Caulk Outlet [Fig. 4225C \| Gasket Seal - ABS Plug; 4226C \| Gasket Seal - Bronze Plug; 4228C \|Taper Thread - Bronze Plug; 4229C \|Taper Thread - ABS Plug]	438 KB
Submittals	Submittal 4231 Series Cleanout	Floor Cleanouts with Round Extra Heavy Duty Cast Iron Tops - Speedi-Set Outlet [Fig. 4231L \| Gasket Seal - ABS Plug; 4232L \|Gasket Seal - Bronze Plug; 4234L \|Taper Thread - ABS Plug][Fig. 4233L \| Taper Thread - Bronze Plug - exclusive submittal page]	731 KB
Brochures/Flyers	MGI Corporate Brochure (pdf)	Who we are, Our History, Morris Group International Today	27 MB
Brochures/Flyers	MGI Brands Flyer (pdf)	MGI Brands Flyer (pdf)	718 KB
Brochures/Flyers	Cleanouts Flyer (pdf)	Flyer for Cleanouts	847 KB
Manuals	Technical Data for Cleanouts	Technical Data for Cleanouts	906 KB
Ordering	Order Guidelines for Cleanouts	Order Guidelines for Cleanouts	120 KB
Parts Manuals	Parts Order Guide for Cleanouts	Parts Order Guide for Cleanouts	910 KB
Revit/BIM/ITM Files	4220S Cleanout Revit Drawing	Floor Cleanout with "Twis-To-Floor®" Adjustable Round Cast Iron Top [4220S02-04 \| Extra-Heavy-Duty Top, Gasket Seal - ABS Plug for 2", 3", 4" pipe sizes]	736 KB
Revit/BIM/ITM Files	4223S Cleanout (rfa/zip)	Floor Cleanout [4223S02-04 \| Extra-Heavy-Duty Top, Taper Thread - Bronze Plug for 2", 3", 4" pipe sizes; 4223S06-06 \| Heavy Duty Top, Taper Thread - Bronze Plug for 6" pipe size; 4223S06-08 \| Heavy Duty Top, Taper Thread - Bronze Plug for 8" pipe size]	1 MB
Specifications	Specifications for Cleanouts	Specifications for Cleanouts	217 KB

Can't find what you are looking for? Get in touch

Specifications

Shows specifications for standard configuration. Configuration options may change specifications.

Variations	Flashing Flange -F, Flashing Flange and Clamp -F-C, Vandal Proof -U - Top, (2) 3/8” (10) Tappings -TAP
Optional Materials	Galvanized Cast Iron -G, Polished Bronze Top - PB
Product Type	Cleanout

Models

Speedi-Set Outlet
4231L | Gasket Seal - ABS Plug
4232L |Gasket Seal - Bronze Plug
4233L | Taper Thread - Bronze Plug
4234L |Taper Thread - ABS Plug
