Model 9614 - 9615
General Purpose Floor Drains For Medium Duty Use
This 14 Gauge, Type 304 Stainless Steel General Purpose floor drain is designed for installation in environments that require requiring fixtures that help maintain consistently high levels of sanitation and that can withstand corrosive liquids (such as in food handling or chemical processing plants). This model is protected from larger debris by a 8” loose-set medium duty slotted stainless steel grate. A USDA compliant model is also available.
Downloads
Resource Type | Title | Description | Answers | File Size | Action | |
|---|---|---|---|---|---|---|
 | | 908 KB | ||||
 | | 0 | 60 KB | |||
| | 0 | 38 KB | |||
| | 0 | 55 KB | |||
| | 0 | 53 KB | |||
 | | 0 | 436 KB | |||
| | 0 | 288 KB | |||
| | 0 | 408 KB | |||
| | 0 | 312 KB | |||
| | 0 | 588 KB | |||
| | 0 | 1 MB | |||
| | 0 | 1 MB | |||
| | 0 | 865 KB | |||
| | Who we are, Our History, Morris Group International Today | 0 | 7 MB | ||
| | Stainless Steel Drainage Products | 0 | 3 MB | ||
| | MGI Brands Flyer (pdf) | 0 | 718 KB | ||
| | Competitive Cross Reference for Stainless Steel Drains (pdf) | 0 | 68 KB | ||
| | NSF Certified Stainless Steel Drains (pdf) | 0 | 1009 KB |
Specifications
| Variations | Anchor Flange -F, Flange & Flashing Clamp -FC, Sediment Bucket -B, Vandal Proof Grate -U, Dome Bottom Strainer -DBS, 1/2"(13) Trap Primer/ Connection -P050, (2) 3/8” (10) Tappings -TAP |
| Optional Materials | Type 316 Stainless Steel -316 |
| Compliance/Certifications | NSF |
