Trap Standards for Service Sinks

Name: Trap Standards for Service Sinks
Brand: Jay R. Smith Mfg. Co.
SKU: 9110-9140

Find A Representative

Figure 9110-9140

Submittal

Submittal 9100 Series Trap

Model 9110-9140

Trap Standards for Service Sinks

This trap is for use with all cast iron service sinks. Options include "S" trap for 3" iron, or soil pipe, "S" trap for 3" soil pipe hub, and DIA

CALIFORNIA WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov - Learn More about this warning

Downloads

Resource Type	Title	Description	File Size
Submittals	Submittal 9100 Series Trap	Specialties - Traps for Service Sink [Wall Outlets 9110, 9114, 9116, 9118, 9120, 9124, 9126, 9128; S-Trap Soil Pipe 9130, 9140]	601 KB
Drawings	9100 Series Trap CAD Drawings	Specialties - Traps for Service Sink [Wall Outlets 9110, 9114, 9116, 9118, 9120, 9124, 9126, 9128; S-Trap Soil Pipe 9130, 9140]	74 KB
Brochures/Flyers	MGI Corporate Brochure (pdf)	Who we are, Our History, Morris Group International Today	27 MB
Brochures/Flyers	MGI Brands Flyer (pdf)	MGI Brands Flyer (pdf)	718 KB
Ordering	Order Guidelines for Specialties	Order Guidelines for Specialties	268 KB

Can't find what you are looking for? Get in touch

Specifications

Shows specifications for standard configuration. Configuration options may change specifications.

Variations	Acid Resistant Coated Inside/Outside -ARIO (Cast Iron Trap Only), 1 1/2"(38) Overflow Connection -N15 (Except Fig. 9110), For use with Stainless Steel Sink add Suffix -SS to Figure Number Selected, (2) 3/8” (10) Tappings -TAP
Product Type	Trap

Models

9110 | 2" Size Wall Outlet - Cast Iron
9114 | 2" Size Wall Outlet - All-Bronze - Military Specifications
9116 | 2" Size Wall Outlet - Sil-Braze Outlet - All-Bronze - Military Specifications
9118 | 2" Size Wall Outlet - Sil-Braze Outlet with Sil-Braze Grooves
9120 | 3" Size Wall Outlet - Cast Iron
9124 | 3" Size Wall Outlet - All-Bronze
9126 | 3" Size Wall Outlet - Sil-Braze Outlet - All-Bronze
9128 | 3" Size Wall Outlet - Sil-Braze Outlet with Sil-Braze Grooves
9130 | "S" Trap for 3" Iron or Soil Pipe - Cast Iron
9140 | "S" Trap for 3" Soil Pipe Hub - Cast Iron
