Roof Drain and Overflow Drain

Name: Roof Drain and Overflow Drain
Brand: Jay R. Smith Mfg. Co.
SKU: 1850

Find A Representative

Figure 1850

Submittal

2 available

Model 1850

Roof Drain and Overflow Drain

Designed to save installation costs and simplify installation, the roof and overflow drains of this unit are attached to a single deck plate. This permits both 8-1/2” drains to be secured to the roof deck from above the roof, eliminates the need for an underdeck clamp, and requires only one roof penetration. The roof drain has a combined flashing clamp and gravel stop. The overflow drain is fitted with a combined flashing clamp and 2” water dam. The pair are constructed of Duco coated cast iron and protected by polyethylene dome strainers.

CALIFORNIA WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov - Learn More about this warning

Downloads

Resource Type	Title	Description	File Size
Submittals	Submittal 1850 Roof Drain (pdf)	Roof Drain and Overflow [1850C \| Caulk Bottom Outlet; 1850T \| Threaded Bottom Outlet; 1850Y \| No-Hub Bottom Outlet]	593 KB
Drawings	1850 Roof Drain (dwg)	Roof Drain and Overflow [1850C \| Caulk Bottom Outlet; 1850T \| Threaded Bottom Outlet; 1850Y \| No-Hub Bottom Outlet]	177 KB
Drawings	1851 Roof Drain (dwg)	Special Purpose Combination Roof Drain and Overflow, Featuring 2" High External Water Dam for Overflow [1851C \| Caulk Bottom Outlet; 1851T \| Threaded Bottom Outlet;1851Y \| No-Hub Bottom Outlet]	124 KB
Submittals	Submittal 1851 Roof Drain (pdf)	Special Purpose Combination Roof Drain and Overflow, Featuring 2" High External Water Dam for Overflow [1851C \| Caulk Bottom Outlet; 1851T \| Threaded Bottom Outlet;1851Y \| No-Hub Bottom Outlet]	1 MB
Brochures/Flyers	MGI Corporate Brochure (pdf)	Who we are, Our History, Morris Group International Today	27 MB
Brochures/Flyers	MGI Brands Flyer (pdf)	MGI Brands Flyer (pdf)	718 KB
Manuals	Technical Data for Roof Drains	Technical Data for Roof Drains	2 MB
Ordering	Order Guidelines for Roof Drains	Order Guidelines for Roof Drains	120 KB

Can't find what you are looking for? Get in touch

Specifications

Shows specifications for standard configuration. Configuration options may change specifications.

Variations	Vandal Proof - Dome - U, Underdeck Clamp for 10" Deck Opening -C10, Extension -E - (Specify Height), LXH Speedi-Set® Extra Heavy, Secondary Flashing Clamp -C2, Expansion Joint (Specify Fig.1710), (2) 3/8” (10) Tappings -TAP, 4” (102) Tall S.S. Perforated Gravel Guard -GG04
Product Type	Roof Drain
Optional Materials	Rough Bronze Dome -RBD, Stainless Steel Mesh Over Dome -SSM, Aluminum Dome -AD, Cast Iron Dome -CID, Galvanized Cast Iron Dome -CIDG, Galvanized Cast Iron -G - Body & Collar

Models

Roof Drain and Overflow [submittal]
1850C | Caulk Bottom Outlet
1850T | Threaded Bottom Outlet
1850Y | No-Hub Bottom Outlet

Special Purpose Combination Roof Drain and Overflow, Featuring 2" High External Water Dam for Overflow [submittal]
1851C | Caulk Bottom Outlet
1851T | Threaded Bottom Outlet
1851Y | No-Hub Bottom Outlet
