Name: Deep Sump Promenade Deck Drain
Brand: Jay R. Smith Mfg. Co.
SKU: 1446

Model 1446

Deep Sump Promenade Deck Drain

Our deep sump deck drain is engineered for placement in roof top recreational and parking decks where the Insulated Membrane Assembly (IRMA) method of waterproofing is used. It is fitted with an adjustable extension that allows it to precisely fit the thickness of roof membrane assemblies where recreational promenades are installed over layers of built up felt and asphalt. Protected by a 14" (355) diam. medium duty grate with combined flashing collar and clamp, this Duco coated cast iron drain will securely grip waterproofing membranes with puncturing for a leakproof installation and long service life. Its deep sump and large diameter will clear heavy runoff fast.

CALIFORNIA WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov - Learn More about this warning

Downloads

Resource Type	Title	Description	File Size
Submittals	Submittal 1446 Roof Drain (pdf)	Deep Sump Promenade Deck Drain [1446C \| Caulk Outlet; 1446T \| Threaded Outlet; 1446Y \| No-Hub Outlet]	514 KB
Drawings	1446 Drain (dwg)	Deep Sump Promenade Deck Drain [1446C \| Caulk Outlet; 1446T \| Threaded Outlet; 1446Y \| No-Hub Outlet]	68 KB
Brochures/Flyers	MGI Corporate Brochure (pdf)	Who we are, Our History, Morris Group International Today	27 MB
Brochures/Flyers	MGI Brands Flyer (pdf)	MGI Brands Flyer (pdf)	718 KB
Specifications	Specifications for Roof Drains	Specifications for Roof Drains	230 KB
Manuals	Technical Data for Roof Drains	Technical Data for Roof Drains	2 MB
Ordering	Order Guidelines for Roof Drains	Order Guidelines for Roof Drains	120 KB
Brochures/Flyers	MGI Brands Flyer (pdf)	MGI Brands Flyer (pdf)	718 KB
Brochures/Flyers	MGI Corporate Brochure (pdf)	Who we are, Our History, Morris Group International Today	27 MB

Can't find what you are looking for? Get in touch

Specifications

Shows specifications for standard configuration. Configuration options may change specifications.

Variations	Bucket -B, Expansion Joint (Specify Fig. 1710), L-Shaped Underdeck Clamp -CL, L Speedi-Set® Service Weight - 02(50), 03(75), 04"(100) Sizes Only, LXH Speedi-Set® Extra Heavy., NO-HUB Adaptor - (Specify Fig. 2646Y), Sump Receiver -R, Underdeck Clamp -C, Vandal Proof Grate - U, T Threaded Outlet, 3/8"(10) Dia. Holes - (8) Required -W, (2) 3/8” (10) Tappings -TAP
Optional Materials	Ductile Iron Grate - M, Galvanized Cast Iron -G, Nickel Bronze Top - NB, Polished Bronze Top - PB
Product Type	Roof Drain

Models

Deep Sump Promenade Deck Drain
1446C | Caulk Outlet
1446T | Threaded Outlet
1446Y | No-Hub Outlet
