Name: Medium Duty Cast Iron Floor Drains with 8-1/2" Round Tops and Tractor Grate
Brand: Jay R. Smith Mfg. Co.
SKU: 2120

Model 2120

Medium Duty Cast Iron Floor Drains with 8-1/2" Round Tops and Tractor Grate

Figure 2120 drain body is available in Duco-coated cast iron. This floor drain accepts 8-1/2" (215 mm) diameter cast iron strainers and is engineered to support medium traffic and static loads up to 4,999 lbs. (2,250 kg). For use when wastewater is free of sediment or debris and floor construction requires a shallow drain body. Also available with a side outlet in Figure 2125

CALIFORNIA WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov - Learn More about this warning

Downloads

Resource Type	Title	Description	File Size
Product MasterSpec	MasterSpec: 221319.13, Sanitary Drains (doc)	Floor drains, Floor sinks, Trench drains, Channel drainage systems.	101 KB
Product MasterSpec	MasterSpec: 221319.13, Sanitary Drains (doc)	Floor drains, Floor sinks, Trench drains, Channel drainage systems.	101 KB
Drawings	2125 Floor Drain (dwg)	Medium Duty Floor Drains with 8 1/2" Round Tops and Tractor Grate [Figure 2125 \| Side Outlet; 2120 \| Bottom Outlet]	51 KB
Drawings	2120 Drain (dwg)	Medium Duty Floor Drains with 8-1/2" Round Tops and Tractor Grate [2120 \| Bottom Outlet]	122 KB
Submittals	Submittal 2120, 2125 Floor Drain (pdf)	Medium Duty Floor Drains with 8-1/2" Round Tops and Tractor Grate [Bottom Outlet 2120C \| Caulked, 2120T \| Threaded, 2120Y \| No-Hub; \| Side Outlet 2125C \| Caulked, 2125T \| Threaded]	589 KB
Product MasterSpec	MasterSpec: 221319.13, Sanitary Drains (pdf)	Floor drains, Floor sinks, Trench drains, Channel drainage systems.	227 KB
Brochures/Flyers	MGI Corporate Brochure (pdf)	Who we are, Our History, Morris Group International Today	27 MB
Brochures/Flyers	MGI Brands Flyer (pdf)	MGI Brands Flyer (pdf)	718 KB
Manuals	Technical Data for Floor Drains (pdf)	Technical Data for Floor Drains	637 KB
Parts Manuals	Parts Order Guide for Floor Drains (pdf)	Parts Order Guide for Floor Drains	6 MB
Ordering	Order Guidelines for Floor Drains (pdf)	Order Guidelines for Floor Drains	120 KB
Manuals	Technical Data for Floor Drains (pdf)	Technical Data for Floor Drains	637 KB
Ordering	Order Guidelines for Floor Drains (pdf)	Order Guidelines for Floor Drains	120 KB
Parts Manuals	Parts Order Guide for Floor Drains (pdf)	Parts Order Guide for Floor Drains	6 MB
Product MasterSpec	MasterSpec: 221319.13, Sanitary Drains (pdf)	Floor drains, Floor sinks, Trench drains, Channel drainage systems.	227 KB
Revit/BIM/ITM Files	2120 Floor Drain Revit Drawing	Medium Duty Floor Drains with 8-1/2" Round Tops and Tractor Grate [2120 \| Bottom Outlet]	260 KB

Can't find what you are looking for? Get in touch

Specifications

Shows specifications for standard configuration. Configuration options may change specifications.

Product Type	Floor Drain
Variations	(2) 3/8” (10) Tappings -TAP, Closure Plug -XP, Deflector Grate -DG, Flat Bottom Strainer -FBS, L Speedi-Set® Service Weight, LXH Speedi-Set® Extra Heavy, NO-HUB Adaptor, Sediment Bucket -B, Square Top -S, Trap Primer Connection -P050 1/2" (13), -P075 3/4" (19), Vandal Proof Grate - U, T Threaded Outlet
Optional Materials	Ductile Iron Grate - M, Galvanized -G - Body, Nickel Bronze Strainer -NB, Polished Bronze -PB - Strainer

Models

Duco Cast Iron Body and Flashing Collar with Medium Duty Cast Iron Tractor Grate.

Bottom Outlet
2120C | Caulk Outlet
2120T | Threaded Outlet
2120Y | No-Hub Outlet
Specify outlet pipe size 02"(50), 03"(75), 04"(100), 05"(125), 06"(150)

Side Outlet
2125C | Caulk Outlet
2125T | Threaded Outlet
Specify outlet pipe size 02"(50), 03"(75), 04"(100)
