Figure Number: 0240Y-M54-XK
Contact a Representative

0240Y-M54-XKVertical Fittings with Side Inlet Extra Heavy Duty 1,000 Lbs. for Siphon Jet Water Closet

This contractor labor-saving, shallow rough-in, adjustable fixture support for bariatric duty siphon jet water closet, 0240Y-M54-XK, features no-hub vertical fittings with side inlet, face plate, and a side-mounted base support assembly  When installed correctly it is able to support a pull-out force of 1000 lbs (454 kg).

Figure 0240Y-M58-M54-XK also features an adjustable Nipple and o-ring.

Additional supports are available to facilitate a 750 lbs (340.20 kg) capacity or less.

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov - Learn More about this warning
Shows specifications for standard configuration. Configuration options may change specifications.
  • Product Type
    Water Closet Support
SubmittalSubmittal 0240Y-M54-XK WC Support (pdf)
View
Technical Drawings
0240_XK Support CAD DrawingsVertical Fittings with Side Inlet Extra Heavy Duty 1,000 Lbs. for Siphon Jet Water Closet [0240Y-M54-XK No Hub - Face Plate, Side-Mounted Base Support Assembly; 0240Y-M58-M54-XK also with Adjustable Nipple and O-Ring]ZIP101 KB
0240_XK Support Revit DrawingsVertical Fittings with Side Inlet Extra Heavy Duty 1,000 Lbs. for Siphon Jet Water Closet [0240Y-M54-XK No Hub - Face Plate, Side-Mounted Base Support Assembly; 0240DY--M54-Double Configuration]]ZIP3 MB
Literature / Videos
Submittal 0240Y-M58-M54-XK WC Support (pdf)Adjustable Support for 1,000 Lbs. Weight Capacity Shallow Rough-In Type Siphon Jet Water Closet - No Hub Vertical Fittings with Side Inlet, Face Plate, Side Mounted Base Support Assembly, Adjustable Nipple and O-RingPDF555 KB
Technical Data for Water Closet Supports (pdf)Technical Data for Water Closet SupportsPDF3 MB
Article: Water Closet SupportsArticle: Water Closet SupportsPDF2 MB
Article: Bariatric Water Closet SupportsArticle: Bariatric Water Closet SupportsPDF324 KB
Article: C.J. Erickson Anticipates Needs of Future Scientists with Smith Specialty ProductsArticle: C.J. Erickson Anticipates Needs of Future Scientists with Smith Specialty ProductsPDF419 KB
MGI Corporate Brochure (pdf)Who we are, Our History, Morris Group International TodayPDF8 MB
MGI Brands Flyer (pdf)MGI Brands Flyer (pdf)PDF712 KB
Engineering Newsletter: Vol. 1, Issue 5 (May 2011)0200Y-M54-XX and 0200Y-M54-XK Series Bariatric Water Closet SupportsPDF2 MB
Parts Order Guide for Water Closet SupportsParts Order Guide for Water Closet SupportsPDF4 MB
Order Guidelines for Water Closet SupportsOrder Guidelines for Water Closet SupportsPDF169 KB
Quote Worksheet Smith Drainage SystemsQuote Worksheet Smith Drainage SystemsPDF36 KB
Can't find what you are looking for? Get in touch
Adjustable Support for 750 Lbs Weight Capacity Shallow Rough-In Type Siphon Jet Water Closet - No Hub Vertical Fittings with Side Inlet, Face Plate, and Side Mounted Base Support Assembly
0240LY-M54-XK | Left Hand; 0240RY-M54-XK | Right Hand; 0240DY-M54-XK | Double
Adjustable Support for 750 Lbs Weight Capacity Shallow Rough-In Type Siphon Jet Water Closet - No Hub Vertical Fittings with Side Inlet, Face Plate, Side-Mounted Base Support Assembly, Adjustable Nipple and O-Ring
0240LY-M58-M54-XK | Left Hand; 0240RY-M58-M54-XK | Right Hand; 0240DY-M58-M54-XK | Double
Specify A x B Dimensions
4(100) x 4(100); 5(125) x 4(100); 6(150) x 4(100)
  • 0240Y-M58-M54-XK NO HUB, Face Plate, Side Mounted Base Assembly, Adjustable Nipple and O-Ring
  • 0240Y-M54-XK NO HUB, Face Plate, Side Mounted Base Assembly
