0770Support with Acid Resistant Coated Arms for Flat Slab and High Back Lavatories Set on Masonry or Stud Wall

For securely mounting high back and flat slab lavatories in masonry or stud walls, a pair of epoxy coated heavy gauge steel plates clamp on to wall framing. Support arms coated for acid resistance are bolted to the frontmost plate and will remain exposed under the lavatory upon installation. Leveling screws can be adjusted from underneath the arms to ensure a precise installation. Toggle bolts secure the lavatory to the support arms.

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov - Learn More about this warning

Shows specifications for standard configuration. Configuration options may change specifications.

Product Type
Lavatory and Sink Support

SubmittalSubmittal 0770 Support

View

Technical Drawings

	DWG 0770 Support	DWG 0770 Support	DWG88 KB
	DWG 0772 Support	DWG 0772 Support	DWG89 KB

Literature / Videos

Submittal 0772 Support	Submittal 0772 Support	PDF272 KB
MGI Corporate Brochure (pdf)	Who we are, Our History, Morris Group International Today	PDF8 MB
MGI Brands Flyer (pdf)	MGI Brands Flyer (pdf)	PDF712 KB
Specifications for Lavatory Supports	Specifications for Lavatory Supports	DOC141 KB
Cross Ref Standard Fixture Support vs LaborSaver®	Cross Ref Standard to Labor Saver Fixture Support	PDF241 KB
Technical Data for Lavatory Supports	Technical Data for Lavatory Supports	PDF493 KB
Order Guidelines for Lavatory Supports	Order Guidelines for Lavatory Supports	PDF120 KB
Parts Order Guide for Lavatory Supports	Parts Order Guide for Lavatory Supports	PDF748 KB
